FINNED TUBULAR HEATERS

  • Fins increase heat transfer surface area allowing higher wattage in the same space requirement of non-finned units
  • Available in .312",.375",.430",.475"and.625" element diameter
  • 2 fin diameter selections
  • Continuous spiral fins of steel with rust and corrosion protection to 850°F/455°C
  • Five turns per linear inch of element
  • 38, 50 and 67 watts per square inch
  • Standard terminal is Fig.1 - any terminal design available
  • Stainless steel fins and Stainless steel element available for operation to 1200°F/650°C. Incoloy sheath and fins are available in some diameters for additional protection in high temperature processes
Finned Tubular Heaters
Finned Tubular Heaters
TYPE 1
Type 1
Catalog
Number
WATTS A B C
CFTS-22020
CFTS-32032
CFTS-42040
CFTS-52050
CFTS-62060
CFTS-72070
CFTS-820880
CFTS-92090
CFTS-102010
2000
3000
4000
5000
6000
7000
8000
9000
10000
22
32
42
52
62
72
82
92
102
1
1
1
1
1
1
1
1
1
20
30
40
50
60
70
80
90
100
TYPE 2
Type 2
Catalog
Number
WATTS A B C D
CFTS-22020
CFTSB-24520
CFTSB-34530
CFTSB-44540
CFTSB-54550
CFTSB-64560
CFTSB-74570
CFTSB-84580
CFTSB-945900
CFTSB-1045100
2000
3000
4000
5000
6000
7000
8000
9000
10000
24½
34½
44½
54½
64½
74½
84½
94½
104½
1
1
1
1
1
1
1
1
1
20
30
40
50
60
70
80
90
100
22
32
42
52
62
72
82
92
102
TYPE 3
Type 3
Catalog
Number
WATTS A B C
CFTH-10820
CFTH-15830
CFTH-20840
CFTH-25850
CFTH-30860
CFTH-35870
CFTH-40880
CFTH-45890
CFTH-508100
2000
3000
4000
5000
6000
7000
8000
9000
10000
10 7/8
15 7/8
20 7/8
25 7/8
30 7/8
35 7/8
40 7/8
45 7/8
50 7/8
1
1
1
1
1
1
1
1
1








TYPE 4
Type 4
Catalog
Number
WATTS A B C
CFTHB-10820
CFTHB-15830
CFTHB-20840
CFTHB-25850
CFTHB-30860
CFTHB-35870
CFTHB-40880
CFTHB-45890
CFTHB-508100
2000
3000
4000
5000
6000
7000
8000
9000
10000
10 7/8
15 7/8
20 7/8
25 7/8
30 7/8
35 7/8
40 7/8
45 7/8
50 7/8
1
1
1
1
1
1
1
1
1
